HW5690

Material overview

HW5690 is a casting resin system for prototype parts and mock-ups made by vacuum casting in silicone moulds.

Use the PP-like formulation without component C, or select a PE-like formulation with 20, 30 or 50 parts of component C. The A:B ratio remains 120:100 across these formulations. The ratios below are expressed as parts by weight, not percentages.

The property values below distinguish the four formulations by their component C content. PP-like and PE-like describe prototype behaviour; they do not identify the resin as polypropylene or polyethylene.

Discuss the target material behaviour, part geometry and processing conditions with Haiwoo. Request the current technical and safety information before mixing or casting this system.

The source property table does not specify test methods or the cure schedule. Confirm these details with Haiwoo when comparing materials for your project.

Application focus

Prototype instrument panels, bumpers, equipment housings and covers.

Material information

Material / process

Vacuum casting

PP-like formulation

120 : 100 : 0 parts by weight
A : B : C. No component C is added.

PE-like formulation — C20

120 : 100 : 20 parts by weight
A : B : C. Select the formulation for your target material behaviour.

PE-like formulation — C30

120 : 100 : 30 parts by weight
A : B : C. Select the formulation for your target material behaviour.

PE-like formulation — C50

120 : 100 : 50 parts by weight
A : B : C. Select the formulation for your target material behaviour.

Hardness

C0: 84; C20: 81; C30: 79; C50: 76 Shore D
At 23°C. C0, C20, C30 and C50 refer to the formulations above.

Tensile strength

C0: 36; C20: 30; C30: 28; C50: 26 MPa
At 23°C. C0, C20, C30 and C50 refer to the formulations above.

Flexural modulus

C0: 1300; C20: 1050; C30: 900; C50: 650 MPa
At 23°C. C0, C20, C30 and C50 refer to the formulations above.

Flexural strength

C0: 50; C20: 35; C30: 30; C50: 20 MPa
At 23°C. C0, C20, C30 and C50 refer to the formulations above.

Elongation at break

C0: 50; C20: 60; C30: 65; C50: 90 %
At 23°C. C0, C20, C30 and C50 refer to the formulations above.

Impact strength (unnotched)

C0: 100; C20: 90; C30: 86; C50: 76 kJ/m²
At 23°C. C0, C20, C30 and C50 refer to the formulations above.

Glass transition temperature (Tg)

C0: 85; C20: 78; C30: 75; C50: 65 °C
Glass transition temperature, not a service-temperature rating.

Linear shrinkage

C0: 0.34; C20: 0.34; C30: 0.34; C50: 0.34 %
At 23°C. C0, C20, C30 and C50 refer to the formulations above.

Request the technical and safety data for this material, including processing parameters and test conditions.

Supply & material preparation

Tell us the PP-like or PE-like behaviour you need, your part size, quantity and destination. Formulation selection, packaging, sample availability and lead time are confirmed with your quotation.
