HW8636

Material overview

A two-component low-pressure injection system for PP-like prototype applications.

Designed for a two-component low-pressure injection process. Discuss mixing equipment, tooling and post-curing requirements with Haiwoo.

Tell us the intended application, part geometry and material behaviour you need. Request the current technical and safety information before mixing or casting. Descriptions such as ABS-like and PP-like refer to prototype behaviour.

Material information

Material / process

Low-pressure injection

Mixing ratio

100:125 by weight
A : B. Weigh components for the selected system.

Hardness

78–80 Shore D
ISO 868. Confirm specimen and cure conditions with the current technical data.

Flexural modulus

1800–2000 MPa
ISO 178. Confirm specimen and cure conditions with the current technical data.

Flexural strength

80–90 MPa
ISO 178. Confirm specimen and cure conditions with the current technical data.

Tensile strength

80–82 MPa
ISO 527. Confirm specimen and cure conditions with the current technical data.

Elongation at break

15–16 %
ISO 527. Confirm specimen and cure conditions with the current technical data.

Request the technical and safety data for this material, including processing parameters and test conditions.

Supply & material preparation

Confirm the selected formulation, component packaging, quantity, destination and lead time with your quotation. Sample format and availability are agreed individually.
